Commissioning
Operating Manual PNOZ m B1
1003790-EN-02
| 26
6.7.2.2 Project menu
In the Project menu you can display information about the project that is activated on the
device. You can also activate a different project from the USB memory on the device. See
also Activate project via the display on the base unit [ 23] and reset the project on the
device.
Display Display Description
Info:
Project
\..
Info
History
Information is displayed about the
project activated on the device
Name
Project name
Project
Name:
_programname_
Name of project
Date / Time
Creation data and
time
Project
Date / Time:
2014-01-31
08:45
Date and time that the project was
created
Check sums FS
Overall check sum
and check sums of
main program
Project
Checksums FS:
total AB08
safe F080
without L3 F080
Display of check sums:
} Overall project check sum
} Check sum safe of main program
} Check sum safe of main program
without level 3
Check sums DP
pos x
Check sums of mod-
ule program
DP pos x
Checksums:
safe F108
without L3 AB80
DP pos y
Checksums:
safe F108
without L3 AB80
Display of check sums of module pro-
gram
} Check sum safe
} Check sum safe without level 3
History:
Project history
Project
History
Select
Info
Project information is displayed for
one of the last 16 projects activated
