Pilz PNOZ m B1 User Manual

Technical details
Operating Manual PNOZ m B1
1003790-EN-02
| 35
8 Technical details
General
Certifications CE, EAC (Eurasian), KOSHA, TÜV, cULus Listed
Application range Failsafe
Electrical data
Supply voltage
for Supply to the system
Voltage 24 V
Kind DC
Voltage tolerance -20 %/+25 %
Output of external power supply (DC) 18,5 W
Output of external power supply (DC) at no load 3 W
Max. power dissipation of module 4,5 W
Status indicator Display, LED
Test pulse outputs
Number of test pulse outputs 4
Voltage 24 V
Current 0,32 A
Max. duration of off time during self test 4 ms
Short circuit-proof yes
Potential isolation No
Ethernet interface
Number 2
IP address (automatically off) 169.254.60.1
Connection type RJ45
Transmission rate 10 MBit/s, 100 MBit/s
Times
Simultaneity in the two-hand circuit 0,5 s
Processing time 30 ms
Environmental data
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range 0 - 60 °C
Forced convection in control cabinet off 55 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-30, EN 60068-2-78
Humidity 93 % r. h. at 40 °C
Condensation during operation Not permitted
Max. operating height above sea level 2000 m
EMC EN 61131-2
