Pilz PNOZ m B1 User Manual

Technical details
Operating Manual PNOZ m B1
1003790-EN-02
| 36
Environmental data
Vibration
In accordance with the standard EN 60068-2-6
Frequency 5 - 150 Hz
Acceleration 1g
Shock stress
In accordance with the standard EN 60068-2-27
Duration 11 ms
Airgap creepage
In accordance with the standard EN 61131-2
Overvoltage category II
Pollution degree 2
Protection type
In accordance with the standard EN 60529
Housing IP20
Terminals IP20
Mounting area (e.g. control cabinet) IP54
Mechanical data
Mounting position horizontally on mounting rail
DIN rail
Top hat rail 35 x 7,5 EN 50022
Recess width 27 mm
Max. cable length
Sum of individual cable lengths at the test pulse
output 2 km
Material
Bottom PC
Front PC
Top PC
Connection type Cage clamp terminal, screw terminal
Mounting type plug-in
Conductor cross section with screw terminals
1 core flexible 0,25 - 2,5 mm², 24 - 12 AWG
2 core with the same cross section, flexible without
crimp connectors or with TWIN crimp connectors 0,2 - 1,5 mm², 24 - 16 AWG
Torque setting with screw terminals 0,5 Nm
Conductor cross section with spring-loaded terminals:
Flexible with/without crimp connector 0,2 - 2,5 mm², 24 - 12 AWG
Spring-loaded terminals: Terminal points per connec-
tion 2
Stripping length with spring-loaded terminals 9 mm
Dimensions
Height 101,4 mm
Width 45 mm
Depth 120,2 mm
Weight 209 g

Pilz PNOZ m B1 Specifications

General

Brand	Pilz
Model	PNOZ m B1
Category	Controller
Language	English
