6.7.2.1 Status indicators
Display Display Description
Permanent display
24V
FS Run
ST Run
Diag
Fault
12:00
24V
FS Stop
ST Run
Diag
Fault
12:00
LED display
} A warning symbol shows that a
message is present, which can
be called up
System / User...
System or display mes-
sages
24V 12:00
FS
ST Run
Diag
Fault
x/n System
_systemMsg_
_line2_
_line3_
24V 12:00
FS
ST Run
Diag
Fault
x/n User FS
id:_display_
_element_
_msg_
System message is present
or
User message is present
(user-specific messages that are
created in the PNOZmulti Config-
urator)
