2.1 Unit structure
2 Overview
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
2-2
` LED for:
– Diagnostics
– Supply voltage
– Output circuits
– Input circuits
` Monitors shorts across the inputs through test pulse outputs
` Monitoring of shorts between the safety outputs
` Plug-in connection terminals (either cage clamp terminal or screw ter-
minal)
2.1.3 Chip card
Chip card2-Bestimmung/Gertebeschreibung_multi_Chipkarte
To be able to use the product you will need a chip card.
Chip cards are available with memories of 8 kByte and 32 kByte. For
large-scale projects we recommend the 32 kByte chip card (see Tech-
nical Catalogue). Accessories chapter).
