Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
4-3
4.1 Unit properties
4 Function description
4.1.2.5 Safety mat, muting
Safety ma t, muting4-Funktionen_multi_Basis_Schaltmatte_Muting
4.1.3 Interfaces
Interfaces 4-Funktionen_Schnittstelle_multi_ETH und RS232
The product PNOZ m0pETH has two Ethernet interfaces, the product
PNOZ m0p has one serial interface to
` Download the project
` Read the diagnostic data
` Set virtual inputs for standard functions
` Read virtual outputs for standard functions.
Information on diagnostics via the interfaces can be found in the Special
Applications Technical Catalogue.
The connection to Ethernet is made via the two 8-pin RJ45 sockets.
The Ethernet interface is configured in the PNOZmulti Configurator and
is described in the online help for the PNOZmulti Configurator.
INFORMATION
Detailed information on these functions and connection exam-
ples can be found in the online help for the PNOZmulti Configu-
rator and in the supplement to the "PNOZmulti - special
applications" technical catalogue.
