5-3
5.2 Connecting the base unit and expansion modules
5 Installation
5.2Connecting the base unit and expansion modules5200Connecting the base unit and expansion modules5-Montage_multi_Basis_verbind_mit_Modul_links-PNOZ m0p_BA
Jumpers are used to connect the modules.
There are 2 pin connectors on the rear of the base unit.
A max. of 4 expansion modules plus one fieldbus module may be con-
nected to one base unit.
` Connect the base unit, the expansion modules and the fieldbus mod-
ule using the jumpers supplied.
Jumper
Fieldbus module
Base unit
Expansion module 1 ... 4
Power supply
