2.2 Front view
2 Overview
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
2-4
2.2.3 Key
Key2-Legende_Klemmenbelegung_multi_Basis_ETH+RS232_BA
Key:
` CHIP card:
– Interface chip card
` X1:
– Cascading inputs and outputs CI and CO,
– Test pulse outputs T0 … T3
` X2:
– Semiconductor outputs O0 ... O3,
– Auxiliary output OA0,
– Supply connections
` X3:
– Relay outputs O4 and O5
` X4:
– RJ 232 interface / Ethernet interface
` X5, X6:
– Inputs I0 ... I19
` X7:
– Power supply
` LEDs:
–PWR
–RUN
– DIAG
–FAULT
–I FAULT
–O FAULT
