2-1
2.1 Unit structure
2 Overview
22000OverviewOverview2-2.1Unit structure2100Unit structure2-
2.1.1 Scope of delivery
Scope of delivery2-Lieferumfa ng_Absch l_779 110_B asis_BA
` Base unit PNOZ m0p
` Terminator 779 110
2.1.2 Unit features
Unit features2-Gerätemerkmale_Verwendung
Using the product PNOZ m0p:
Verwendung/Bildunterschrift_multi_Basis
Base units from the PNOZmulti modular safety system
Geraetemerkmale_Zusatz BA Einleitung
The product has the following features:
Gertemerkmale PNOZ m0p
` Can be configured in the PNOZmulti Configurator
` Positive-guided relay outputs:
– 2 safety outputs
Depending on the application, up to PL e of EN ISO 13849-1 and
up to SIL CL 3 of EN IEC 62061
` Semiconductor outputs:
– 4 safety outputs
Depending on the application, up to PL e of EN ISO 13849-1 and
up to SIL CL 3 of EN IEC 62061
– 1 auxiliary output
` 4 test pulse outputs
` 1 cascading input and output; can also be used as a standard output
` 20 inputs for connecting:
– E-STOP pushbuttons
– Two-hand buttons
– Safety gate limit switches
– Reset buttons
– Light beam devices
– Scanners
– Enabling switches
– PSEN
– Operating mode selector switches
– Pressure sensitive mats
` Integrated interface:
– PNOZ m0p: Serial interface RS 232
– PNOZ m0p ETH: Ethernet interface
` Muting function
` Connectable:
– 1 fieldbus module on the left
– 4 expansion modules on the left
