7.1 Messages
7 Operation
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: pilz.gmbh@pilz.de
7-2
7.1.2 Display elements for the Ethernet connection (only PNOZ m0p ETH)
Display elements for the Ethernet connection (only PNOZ m0p ETH)7-ETH_Anzeigeelemente_fuer_Ethernet_LNK_TRF
The operating statuses and fault conditions of the Ethernet connection
are shown via the LEDs LNK (link) and TRF (traffic) at the Ethernet inter-
faces.
The fieldbus module has not been recognised.
Or
The base unit was identified via the PNOZmulti Configurator.
Error on cascading input; unit remains in a RUN condition.
Error on cascading output; unit remains in a RUN condition.
LED Signal Meaning
LNK
(green)
No network connection
Network connection present
TRF (yel-
low)
No data traffic
Data traffic present
