PNOZ s5
Operating Manual PNOZ s5
21397-EN-10
28
Mechanical data 750105 751105 751185
Dimensions
Height 98 mm 100 mm 100 mm
Width 22,5 mm 22,5 mm 22,5 mm
Depth 120 mm 120 mm 120 mm
Weight 235 g 235 g 235 g
Where standards are undated, the 2014-07 latest editions shall apply.
Order no. 750135 –751135
General 750135 751135
Approvals
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
CCC, CE, EAC (Eurasian),
KOSHA, TÜV, cULus Listed
Electrical data 750135 751135
Supply voltage
Voltage 48 - 240 V 48 - 240 V
Kind AC/DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 8 VA 8 VA
Output of external power supply
(DC) 4 W 4 W
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Residual ripple DC 160 % 160 %
Continuous duty 100 % 100 %
Inputs 750135 751135
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 40 mA 40 mA
Start circuit DC 40 mA 40 mA
Feedback loop DC 40 mA 40 mA
Max. inrush current impulse
Current pulse, input circuit 0,2 A 0,2 A
Pulse duration, input circuit 100 ms 100 ms
Current pulse, feedback loop 0,2 A 0,2 A
Pulse duration, feedback loop 60 ms 60 ms
Current pulse, start circuit 0,2 A 0,2 A
Pulse duration, start circuit 60 ms 60 ms
Min. input resistance at power-on 110 Ohm 110 Ohm
