Pilz PNOZ s5 User Manual

PNOZ s5
Operating Manual PNOZ s5
21397-EN-10
29
Inputs 750135 751135
Max. overall cable resistance Rl-
max
Single-channel at UB DC 30 Ohm 30 Ohm
Single-channel at UB AC 30 Ohm 30 Ohm
Dual-channel without detection
of shorts across contacts at UB
DC 30 Ohm 30 Ohm
Dual-channel without detection
of shorts across contacts at UB
AC 30 Ohm 30 Ohm
Dual-channel with detection of
shorts across contacts at UB DC
30 Ohm 30 Ohm
Dual-channel with detection of
shorts across contacts at UB AC 30 Ohm 30 Ohm
Semiconductor outputs 750135 751135
Number 1 1
Voltage 24 V 24 V
Current 20 mA 20 mA
Relay outputs 750135 751135
Number of output contacts
Safety contacts (N/O), instant-
aneous 2 2
Safety contacts (N/O), delayed 2 2
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
Utilisation category of safety con-
tacts
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 6 A 6 A
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 6 A 6 A
Max. power 150 W 150 W
Utilisation category of safety con-
tacts delayed
AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 6 A 6 A
Max. power 1500 VA 1500 VA
DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 6 A 6 A
Max. power 150 W 150 W
