Pilz PNOZ s5 User Manual

PNOZ s5
Operating Manual PNOZ s5
21397-EN-10
31
Conventional thermal current
while loading several contacts
750135 751135
Ith per contact at UB AC
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 6 A 6 A
Conv. therm. current with 2 con-
tacts 6 A 6 A
Conv. therm. current with 3 con-
tacts 6 A 6 A
Conv. therm. current with 4 con-
tacts 6 A 6 A
Ith per contact at UB DC
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact 6 A 6 A
Conv. therm. current with 2 con-
tacts 6 A 6 A
Conv. therm. current with 3 con-
tacts 6 A 6 A
Conv. therm. current with 4 con-
tacts 6 A 6 A
Times 750135 751135
Switch-on delay
With automatic start typ. 180 ms 180 ms
With automatic start max. 330 ms 330 ms
With automatic start after power
on typ. 1.430 ms 1.430 ms
With automatic start after power
on max. 1.900 ms 1.900 ms
With automatic start after power
on typ. 1.470 ms 1.470 ms
With automatic start after power
on max. 2.000 ms 2.000 ms
With manual start typ. 45 ms 45 ms
With manual start max. 85 ms 85 ms
With monitored start with rising
edge typ. 45 ms 45 ms
With monitored start with rising
edge max. 70 ms 70 ms
With monitored start with falling
edge typ. 60 ms 60 ms
With monitored start with falling
edge max. 80 ms 80 ms
Delay-on de-energisation
With E-STOP typ. 15 ms 15 ms
With E-STOP max. 20 ms 20 ms
With power failure typ. 75 ms 75 ms
With power failure max. 110 ms 110 ms
