Pioneer PDP-5000EX User Manual

11
En
Safety Precautions
02
English
CAUTION
• Handles should not be removed or reattached by anyone
other than the professional installation technician or service
personnel.
• If handles must be removed due to specific installation
conditions, the mounting screws should be stored carefully
together with the handles. To ensure safety, the mounting
screws should be tightened to a minimum torque of 2N·m
(20 kgf·cm) when reattaching the handles.
• When moving the display, it should always be carried by two
persons holding the rear handles in the manner shown.
NO!
• Never attempt to move the Plasma Display by holding only
one of the handles.
• When installing the Plasma Display, do not use the handles
as means of hanging the display; also do not use them as
devices to prevent tipping over (see illustration).
Air vents (fan)
Center line
Main unit
a hole
Bolt
12 mm to 18 mm
Attaching surface
Center line
a hole a hole
Rear view dia
g
ram Side view dia
g
ram
Installation
bracket, etc.

Pioneer PDP-5000EX Specifications

General

Depth	98 mm
Width	1282 mm
Height	750 mm
Weight	39800 g
Pixel pitch	- mm
Product color	Black
Audio (L/R) in	1
Noise reduction	Yes
RMS rated power	13 W
Display diagonal	50 \
Display brightness	1000 cd/m²
Display technology	Plasma
Power requirements	AC 110 - 240 V, 50/60 Hz
Contrast ratio (typical)	3000:1
Power consumption (standby)	0.4 W
Power consumption (typical)	420 W
