Part Names
05
English
Part Names
Main unit
Main unit
1 MAIN
POWER
switch
2ON
indicator
3 STANDBY
indicator
4
Remote control sensor
5
Handles
Operation panel on the main unit
6
STANDBY/ON
button
7 INPUT
button
8 HOME MENU
button
9 ADJUST (///)
buttons
10 VOLUME +/–
buttons
11 ENTER/DISP.
button
12 RETURN
button
13 SCREEN SIZE
button
POWER ON STANDBY
7
6
8
9
11
12
13
10
123
4
5
Note
The unit’s operating panel will become
inoperable if connected speakers are
installed too near the main unit.
Operation panel on the main unit
