PDP-507CMX
11
5678
56
7
8
C
D
F
A
B
E
(1) REAR SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-507CMX/KUC, PDP-50MXE20/LDFK5, TYVXK5 and PDP-50MXE20-S/LDF5 are constructed the same
except for the following:
Mark
No. Description Part No.
1 Rear Case (507CMX) ANE1659
2 Inner Grip Assy AMR3434
3 Rear Case Cushion AEB1468
NSP 4 Name Label See Contrast table (2)
5 Caution Label See Contrast table (2)
6Terminal Label A See Contrast table (2)
7Terminal Label B See Contrast table (2)
8Terminal Label C See Contrast table (2)
9 Bottom Cover (CMX) ANG2953
10 Gasket C ANK1872
11 Gasket D ANK1873
12 Gasket J ANK1890
13 Screw TBZ40P080FTB
14 Screw AMZ30P060FTB
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-507CMX
/KUC
PDP-50MXE20
/LDFK5
PDP-50MXE20
/TYVXK5
PDP-50MXE20-S
/LDF5
NSP 4 Name Label (507CMX) AAL2795 Not used Not used Not used
NSP 4 Name Label (50MXE20) Not used AAL2796 AAL2882 Not used
NSP 4 Name Label (50MXE20-S) Not used Not used Not used AAL2797
5 Caution Label (M) AAX3304 AAX3304 Not used AAX3304
5 Caution Label Not used Not used AAX3295 Not used
6Terminal Label A (507CMX) AAX3373 AAX3373 Not used AAX3373
6Terminal Label A Not used Not used AAX3444 Not used
7Terminal Label B (CMX) AAX3251 AAX3251 Not used AAX3251
7Terminal Label B Not used Not used AAX3293 Not used
8Terminal Label C (507CMX) AAX3374 AAX3374 Not used AAX3374
8Terminal Label C Not used Not used AAX3445 Not used
