Pioneer PDP-507CMX Service Manual

PDP-507CMX
127
5678
56
7
8
C
D
F
A
B
E
7. ADJUSTMENT
7.1 ADJUSTMENT REQUIRED WHEN THE SET IS REPAIRED OR REPLACED
PARTS CHANGE OF NOTES
POWER SUPPLY Unit
DIGITAL Assy
MAIN Assy
Refer to the "7.2 BACKUP OF THE ADJUSTMENT DATA"
and
"8. SERVICE FACTORY MODE"
SENSOR Assy
Other assemblies
No adjustment required
Service Panel Assy
Refer to the "7.3 HOW TO CLEAR HISTORY DATA" and
"7.4 EXCHANGE THE SERVICE PANEL"
When any of the following assemblies is replaced
Refer to "7.3 HOW TO CLEAR HISTORY DATA" and
"7.6 PROCEDURE WHEN REPLACING THE POWER
SUPPLY UNIT".
Writing of backup data is require.
Refer to the "7.2 BACKUP OF THE ADJUSTMENT DATA"
Writing of backup data is reguire.
Refer to the "7.2 BACKUP OF THE ADJUSTMENT DATA"
50Y MAIN DRIVE Assy No adjustment required
50Y SUB DRIVE Assy No adjustment required
50X MAIN DRIVE Assy No adjustment required
50X SUB DRIVE Assy No adjustment required
