Pioneer PDP-507CMX Service Manual

PDP-507CMX
122
1234
1234
C
D
F
A
B
E
6. DISASSEMBLY
6.1 PCB LOCATION
LED2 Assy KEY Assy
50 ADDRESS
L Assy
COMMSLOT
Assy
SENC AssyCOMMSLOT IF
Assy
AUDIO
Assy
VSIF Assy
50 ADDRESS
S Assy
50 ADDRESS
S Assy
50 ADDRESS
L Assy
50 Y MAIN DRIVE
Assy
50 X MAIN DRIVE
Assy
50 SCAN B Assy50 SCAN A Assy
50 DIGITAL
Assy
LVDS
Assy
MAIN Assy
POWER SUPPLY
Unit
Rear view
Front view Front view
50 Y SUB DRIVE
Assy
SENSOR
Assy
SENB Assy SEND AssyDD Assy
50 X SUB DRIVE
Assy
