PDP-507CMX
132
1234
1234
C
D
F
A
B
E
7.2.2 BACKUP WHEN THE MAIN ASSY REPLACED
How to Copy Backup Data
Data to be backed up
1. System Requirements for the PC and PC settings
Operation environment
PC with Windows 95/98/Me or Windows NT/2000/XP installed, and with one or more serial ports.
Note: According to specifications of hardware, the baud rate setting may be limited.
File structure
MCUT22SPio_E.exe Executable file for the utility (English version)
MCU_DATA.INI MCU data file
MCU_01.INI MCU information file
Installation of software for rewriting
Create a folder and copy the following files into that folder:
• MCUT22SPio_E.exe
• MCU_DATA.INI
• MCU_01.INI
2. Connect the PC to the PDP.
Use an RS-232C straight cable.
3. Set the Main Power switch of the PDP to OFF.
• Hour-meter of product
• Serial No of product
• User adjustment value
(It became an initial value when entering the integrator mode.)
• Integrator adjustment value
To Next Page
