8.3 FACTORY MENU MODE
Moving the keys of [ ] and [ ], select the numerals and characters of the
serial number that is listed in the serial label located on the rear surface of the product. Register the
serial number. (Blank → 0 to 9→A to Z)
Moving the keys of [ ] and [ ], select the next digit by means of a cursor.
Adjusting conditions
Adjustments should be carried out in the procedures below. However, any adjustments other than the below are not required.
• When the "PDP module" is replaced, adjustmentsshould conform to the adjusting items below.
[HOW TO CLEAR HISTORY DATA] [BACKUP WHEN THE MAIN UNIT IS ADJUSTED]
• When the "MAIN Assy" is replaced, adjustments should conform to the adjusting item of [ 1, 2 ] specified below.
1. Adjustments after the replacement of the MAIN Assy (Using the remote control)
1-1. Product serial No. registration
Press the keys in the order of [PIP SHIFT] → [SET] → [Clear] → [PIP SHIFT] in order to enter the
factory adjustment menu.
Press the [Clear] or [ID No. set] key to select the [MONITOR INFORMATION] No. menu.
(Example : PDP-507CMX)
Press the [SCREEN SIDE] key 4 times to display a cursor in the lower column of [SERIAL/NUMBER].
(1)
(2)
(3)
(6)
(5)
(4)
Repeat the processes of (4) and (5) above and register the serial number completely.
No modification is possible here because this
modification is already finished.
Factory shipment setting (initial setting).
No modification is possible here because
registration is already finished at the time of
shipment in terms of maintenance parts.
MENU/ENTER
NEXT
EXIT
PREV 9 / 10
+ M O N I T O R I N F O R M A T I O N
M O D E L N A M E
P D P - 5 0 7 C M X
S E R I A L / N U M B E R
:
S O F T W A R E V E R S I O N
: E M 0 3
U S A G E T I M E
: 0 0 0 0 0 H
T 1 0 2 5 T 2 0 2 5
T 3 0 2 5 T 4 - - -
MENU/ENTER
NEXT
EXIT
PREV 9 / 10
+ M O N I T O R I N F O R M A T I O N
M O D E L N A M E
P D P - 5 0 7 C M X
S E R I A L / N U M B E R
:
S O F T W A R E V E R S I O N
: E M 0 3
U S A G E T I M E
: 0 0 0 0 0 H
T 1 0 2 5 T 2 0 2 5
T 3 0 2 5 T 4 - - -
