2-2. Factory shipment setting (Initial setting)
(1) Press the [CLEAR] or [ID SELECT] key to select the [FUNCTION] menu.
(2) Move the keys of [ ] and [ ] to the item of [SHIP]. Then, move the
keys of [ ] and [ ] to select [DESTINATION ALPHABETS] shown below.
(The asterisks * shown below denote the numerals or the characters.)
A: PDP-507CMX
J: PDP-507CMX-JP
G : PDP-50MXE20
GS : PDP-50MXE20-S
(3) Press the keys in the order of [MUTE]→ [ ] → [ ] →[MUTE] to make "Factory shipment setting".
When "Factory shipment setting" is executed, the red characters of [SET] is shown for about 5 seconds
on the right side of the [DESTINATION ALPHABETS].
The setting is finished when these red characters of [SET] go out. In regard to the factory shipment setting
values, refer to the descriptions given below.
Press the keys of the remote control in the order of [PIP SHIFT] → [SET] → [CLEAR] → [PIP SHIFT]
in order to withdraw from the Factory shipment setting.
(4)
MENU/ENTER NEXT EXIT PREV 10 / 10
+ FUNCTION
SCART OFF PLE TEST OFF ––
SHIP A ROTATE PTN 1
LIMIT–VD OFF
LIMIT–PC ON
GAMMA–MD 12
VOL OFFSET
2
EXT–PC OFF
MENU/ENTER NEXT EXIT PREV 10 / 10
+ FUNCTION
SCART OFF PLE TEST OFF ––
SHIP A SET ROTATE PTN 1
LIMIT–VD OFF
LIMIT–PC ON
GAMMA–MD 12
VOL OFFSET
2
EXT–PC OFF
