Pioneer PDP-507CMX Service Manual

PDP-507CMX
62
1234
1234
C
D
F
A
B
E
4.16 POWER BLOCK DIAGRAM
POWER SUPPLY UNIT
DD ASSY (DC-DC Convertor)
P12
P12 PV
A+12
A+6V
FU9001
FU9002
IP
VCCA+6V
VCC+12V
POMUTE PULL UP
AUDIO AMP IC5306 (NJM4580) AUDIO SW CI5308 (NJM2750)
12→9
IC5303 (NJM78M09DL1A)
F5025
FB
9→6.5 IC9002 (PQ200WNA1ZPH)
FA
FAN
FB
FC
DD ASSY
A_RGB_SEL IC5601 (BA7657) B_RGB_SEL IC5901 (BA7657) A_LPF IC5602 (SM5301) B_LPF IC5905 (SM5301) DSUB_OUT_SEL IC5004 (BA7657) IN1_DET Tr B_SYNC_SEP IC5903 (BA7078)
FB
F6504
FB
B_SYNC_SEL & 5 to 3 IC5904 (LCX157)
B_SYNC_SEL IC5902 (VHC153)
I/O EXP IC5301 (BU2152) EDID ROM IC5003 (BR24C21F) A_SYNC_SEP IC5605 (BA7078) DSUB_OUT_BUF IC5606 (LVC2G126) DSUB_OUT_BUF IC5008 (LVC2G126)
B_AD IC6701 (TDA8754) A_AD IC6501 (TDA8754)
F6704
ana ana
digi digi digi digi
FD
FAN FAN
FE
VCC+9V_2
DSUB OUT IC5007 (EL5362) COMM SLOT
12→VARIABLE IC9001 (PQ20WZIU) 6→5 IC5009 (BA05FP) 6→3.3 IC6502 (NJM2846DL3-33) 6→3.3 IC6702 (NJM2846DL3-33) 7V→5V
IC5006 (NJM2846DL3-05)
7→5 IC7006 (PQ20WZ1U)
5→3 IC7003 (PQ20WZ1U)
VDD+3SA
R
DVI RECEIVER IC7001 (SII1169) A_SYNC_SEL IC5603 (VHC153)
A_SYNC_SW IC9504 (LVC08) INPUT SCHMITT IC5002 (LVC14A) A_SYNC_SEL & 5 to 3 IC5604 (LCX157)
FU9003
IP
VDDM7
VCC+9V
REGULATOR
VCC+5V
VCC+3.3ADA
VCC+3.3ADB
VCC+5S
VDD+3S
M+7
PM
IP
VCC+6.5V
P5 P5 P8 P8
VCC+6.5V VCC+6.5V
VCC+12
VCC+16.5V
VCC+5.1V
VCC+12
STB3.3V
