Pioneer PDP-507CMX Service Manual

PDP-507CMX
26
1234
1234
C
D
F
A
B
E
3. PCB PARTS LIST
77
77
LIST OF WHOLE PCB ASSEMBLIES
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Mark Symbol and Description
PDP-507CMX
/KUC
PDP-50MXE20
/LDFK5
PDP-50MXE20
/TYVXK5
PDP-50MKE20-S
/LDF5
NSP 1..PANEL CHASSIS ASSY AWU1148 AWU1148 AWU1148 AWU1148
NSP 2..50 ADDRESS ASSY AWV2303 AWV2303 AWV2303 AWV2303
NSP 3..50 ADDRESS L ASSY AWW1141 AWW1141 AWW1141 AWW1141
NSP 3..50 ADDRESS S ASSY AWW1142 AWW1142 AWW1142 AWW1142
NSP 2..50 SCAN ASSY AWV2304 AWV2304 AWV2304 AWV2304
NSP 3..50 SCAN A ASSY AWW1147 AWW1147 AWW1147 AWW1147
NSP 3..50 SCAN B ASSY AWW1148 AWW1148 AWW1148 AWW1148
NSP 1..50 X DRIVE ASSY AWV2305 AWV2305 AWV2305 AWV2305
2..50 X MAIN DRIVE ASSY AWW1143 AWW1143 AWW1143 AWW1143
2..50 X SUB DRIVE ASSY AWW1144 AWW1144 AWW1144 AWW1144
NSP 1..50 Y DRIVE ASSY AWV2306 AWV2306 AWV2306 AWV2306
2..50 Y MAIN DRIVE ASSY AWW1145 AWW1145 AWW1145 AWW1145
2..50 Y SUB DRIVE ASSY AWW1146 AWW1146 AWW1146 AWW1146
NSP 1..50 DIGITAL ASSY AWV2436 AWV2436 AWV2436 AWV2436
2..50 DIGITAL ASSY AWW1241 AWW1241 AWW1241 AWW1241
2..SENSOR ASSY AWW1140 AWW1140 AWW1140 AWW1140
NSP 1..MAIN ASSY (50CMX) AWV2377 AWV2403 AWV2403 AWV2403
2..MAIN ASSY AWW1199 AWW1201 AWW1201 AWW1201
2..VSIF ASSY AWW1200 AWW1202 AWW1202 AWW1202
NSP 1..SUB ASSY (50CMX) AWV2406 AWV2406 AWV2406 AWV2406
2..SENB ASSY AWW1217 AWW1217 AWW1217 AWW1217
2..SENC ASSY AWW1218 AWW1218 AWW1218 AWW1218
2..SEND ASSY AWW1219 AWW1219 AWW1219 AWW1219
2..AUDIO ASSY AWW1220 AWW1220 AWW1220 AWW1220
2..COMMSLOT ASSY AWW1221 AWW1221 AWW1221 AWW1221
2..COMMSLOT IF ASSY AWW1222 AWW1222 AWW1222 AWW1222
2..KEY ASSY AWW1223 AWW1223 AWW1223 AWW1223
2..LED2 ASSY AWW1224 AWW1224 AWW1224 AWW1224
NSP 1..MDIF ASSY (50CM) AWV2419 AWV2419 AWV2419 AWV2419
2..LVDS ASSY AWW1226 AWW1226 AWW1226 AWW1226
2..DD ASSY AWW1227 AWW1227 AWW1227 AWW1227
> 1..POWER SUPPLY UNIT AXY1151 AXY1151 AXY1151 AXY1151
