Pioneer PDP-507CMX Service Manual

PDP-507CMX
191
5678
56
7
8
C
D
F
A
B
E
10.3
LED INFORMATION
Power OFF (Indicator OFF) Power ON (Indicator ON) Standby Power Management Power-Down Shutdown No Backup Copy (Panel) During Main micro- computer rewriting During MD micro- computer rewriting (During MOD) During ASTRA rewriting (During PNL)
Not lit Green: Lit Red: Lit Green flashes at intervals of 1000ms
Red flashes at intervals of 500ms for 1 to n times with 2500ms of pause between switching. Green flashes at intervals of 500ms for 1 to n times with 2500ms of pause between switching. Red lit, and green flashes at intervals of 200ms Red flashes at intervals of 300ms Red flashes at intervals of 100ms Red and green flashes at intervals of 100ms
Red
Green
Red
Green
Red
Green
Red
Green
Red
Green
Red
Green
Red
Green
Red
Green
Red
Green
Red
Green
LED Lighting PatternStatus Remarks
1000ms
500ms 500ms
200ms
300ms
300ms
100ms
100ms
100ms
100ms
300ms
300ms
300ms
300ms
300ms
300ms
300ms
300ms
300ms 300ms
300ms
500ms 500ms
2500ms 2500ms
1000ms
(1 time) (1 time)
(n times) (n times)
