Pioneer PDP-507CMX Service Manual

PDP-507CMX
13
5678
56
7
8
C
D
F
A
B
E
(1) FRONT SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-507CMX/KUC, PDP-50MXE20/LDFK5, TYVXK5 and PDP-50MXE20-S/LDF5 are constructed the same
except for the following:
Mark
No. Description Part No.
1 LED2 Assy AWW1224
2Front Case Assy (507CMX) See Contrast table (2)
3Front Case Cushion AEB1471
4 Sheet AED1289
5 Pionner Name Plate See Contrast table (2)
6 IR Sheet (50XM6) AMR3625
7 PCB Spacer AEC1947
8 8P Housing Wire (J155) ADX3447
9 Filter CTX1054
10 Binder AEC-093
11 Screw AMZ30P060FTB
Mark No. Symbol and Description
PDP-507CMX
/KUC
PDP-50MXE20
/LDFK5
PDP-50MXE20
/TYVXK5
PDP-50MXE20-S
/LDF5
2Front Case Assy (507CMX) AMB2994 AMB2994 AMB2994 Not used
2Front Case Assy (50MXE-S) Not used Not used Not used AMB2997
5 Pioneer Name Plate AAM1112 AAM1112 AAM1112 AAM1101
