Pioneer PDP-507CMX Service Manual

PDP-507CMX
15
5678
56
7
8
C
D
F
A
B
E
(1) CHASSIS SECTION (1/2) PARTS LIST
(2) CONTRAST TABLE
PDP-507CMX/KUC, PDP-50MXE20/LDFK5, TYVXK5 and PDP-50MXE20-S/LDF5 are constructed the same
except for the following:
Mark
No. Description Part No.
1 COMM SLOT IF Assy AWW1222
2AUDIO Assy AWW1220
3 COMM SLOT Assy AWW1221
4 KEY Assy AWW1223
> 5Fan Motor 80x25L AXM1061
6 Floating Rubber 80 AEB1427
7 Omega Lock AEC2108
8 Mini Clamp AEC1805
9Fan Bracket (80) ANG2987
10 COMM I/F Bracket (CMX) ANG2859
11 Ferrite Core ATX1039
12 Wire Saddle AEC1797
13 COMM Rail (CMX) AMR3486
14 9P Housing Wire (J145) ADX3442
NSP 15 Audio Heat Sink ANH1648
16 Radiation Sheet AUDIO AMR3507
17 Audio Bracket (CMX) ANG2998
18 Gasket C ANK1872
19 Nylon Rivet AEP-211
20 Protection Sheet 92 AMR3643
21 Slot Panel 92 ANG2611
22 40P Housing Wire (J151) ADX3445
23 Slot Panel 262 (N) ANG2610
24 Gasket G ANK1878
25 Gasket B ANK1849
26 Gasket F ANK1876
27 Wire Saddle AEC1745
28 Slot Spring T94 ABK1034
29 Slot Spring B92 ABK1035
30 Sub Frame L (CMX) ANG2975
31 Sub Frame R (CMX) ANG2978
32 Slot Spring T130 ABK1032
33 Slot Spring B126 ABK1033
34 Multi base Support ANG3031
> 35 AC Inlet (CN1) AKP1311
36 Gasket L ANK1907
37 Terminal Panel (CMX) Assy ANG2989
38 Rivet A BEC1158
39 Front Chassis L (50XM6) ANA2008
40 Front Chassis R (50XM6) ANA2010
> 41 Power Switch (S1) ASG1094
42 Panel Holder (50XM6) ANG3003
43 Front Chassis U Assy (507C) ANA2015
44 Panel Holder H (50) ANG2769
45 Gasket A ANK1848
46 Gasket K ANK1897
47 Gasket H ANK1888
48 Front Chassis B Assy (507C) ANA2053
49 Bracket LED (50XM6) ANG3000
50 Gasket D ANK1873
51 Filter CTX1090
52 Bracket Control (50XM6) ANG3001
53 3P Housing Wire (J153) ADX3446
54 Control Button (CMX) AAC1559
55 Sheet B AED1284
56 Control Cover (507C) See Contrast table (2)
57 Scan Sheet (50XM6) AMR3617
58 Screw BPZ30P080FTB
59 Screw TBZ40P080FTB
60 Screw ABA1351
61 Screw BMP40P080FBN
62 Screw BBA1051
63 Screw ABA1318
64 Screw AMZ30P060FTB
65 Screw BBZ30P060FTC
> 66 Housing Wire (J133) ADX3433
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-507CMX
/KUC
PDP-50MXE20
/LDFK5
PDP-50MXE20
/TYVXK5
PDP-50MXE20-S
/LDF5
56 Control Cover (507C) AMR3622 AMR3622 AMR3622 Not used
56 Control Cover (42MXE) S Not used Not used Not used AMR3595
