PDP-507CMX
157
5678
56
7
8
C
D
F
A
B
E
8.4.5 PANEL-1 ADJ (+)
A.PNEL
L/1
[
BT60VS
]
FACT
AJPNEL–1AD )(+
A.PNEL
–/–
[
––60VS
]
FACT
O>VLOF TFSE <=
AJPNEL–1AD
2:1 8
B–SD 3 2060 –DIG HJ–B7
B–SD 3 2060 –DIG HJ–B7
1
5
10
15
16
15 10 15 20 25 30 32
1
5
10
15
16
15 10 15 20 25 30 32
• Timing and voltage for the driving pulse are set. At the upper right of the screen, the wb table and frequency table
indicating operation status are displayed, and at the lower left of the screen, the item for the upper nested layer
(PANEL-1 ADJ [+]) is displayed. Pressing the SET key shifts the screen to the next nested layer below for item selection.
When the screen is shifted to the next nested layer below, a subitem is indicated on the 3rd line,
and detailed data are indicated on the 15th line.
• When the screen is shifted to the next nested layer below, a subitem is indicated
on the 3rd line, and detailed data are indicated on the 15th line.
• When the screen is shifted to this layer while the RASTER MASK is selected,
the Panel W/B setting is temporarily set to default.
<DOWN> : Shifting to PANEL-2 ADJ (+)
<UP> : Shifting to SHUT DOWN
<SET> : Shifting to the next nested layer
Key operation
<DOWN> : Shifting to the next item
<UP> : Shifting to the previous item
<RIGHT> : Adding by one to the adjustment
value
<LEFT> : Subtracting by one from the
adjustment value
<VOL+> : Adding by 10 to the adjustment
value
<VOL-> : Subtracting by 10 from the
adjustment value
<SET> : Determining the adjustment value
and shifting to the upper layer
Key operation
<Lower-layer items of PANEL-1 ADJ>
No. Items Adjustment/Setting Value RS-232C Command
1 X-SUS B <=> 120 to 136 XSB
2 Y-SUS B <=> 120 to 136 YSB
4 Y-SUSTAIL T2 <=> 120 to 136 YTB
3 Y-SUSTAIL T1 <=> 120 to 136 YTG
5 Y-SUSTAIL W <=> 120 to 136 YTW
6 XY-RST W1 <=> 120 to 136 RSW
7 XY-RST W2 <=> 120 to 136 RYW
8 VOL SUS <=> 000 to 255 VSU
9 VOL OFFSET <=> 000 to 255 VOF
10 VOL RST P <=> 000 to 255 VRP
11 SUS FREQ. <=> MODE1 to MODE8 SFR
To Next Page
