Pioneer PDP-507CMX Service Manual

PDP-507CMX
32
1234
1234
C
D
F
A
B
E
CAPACITORS
C2401 ACE1177
C2402 ACH1425
C2403,2404 CKSRYB104K25
C2405,2407,2412 CKSRYB104K16
C2408 CEHAT101M16
C2409 CEHAT470M25
C2410 CEHAT101M25
C2411 ACH1450
C2413 CEHAT221M16
C2421 ACH1451
[50Y D-D CON BLOCK]
SEMICONDUCTORS
IC2501,2502,2504 PS2701A-1(L)
IC2503 BA10358F
IC2506,2514 TA76431FR
Q2501,2506,2511 2SD1898
Q2502,2507 2SA1576A
Q2503,2515 DTC143EUA
Q2504,2509,2513 HN1C01FU
Q2505 2SC2713
Q2508 2SA2005
Q2510 2SA1163
Q2512,2514 2SC4081
Q2520 2SC2412K
D2501,2503,2510,2516 CRH01
D2502,2512,2518 1SS301
D2504,2508 UDZS4R7(B)
D2505,2507,2513,2517 1SS355
D2509 D1FL40
D2511 1SS302
D2515,2521 UDZS5R1(B)
D2519,2520,2523 1SS355
D2522 UDZS5R6(B)
D2524 UDZS15(B)
MISCELLANEOUS
T2501 ATK1156
T2502 ATK1161
T2503 ATK1159
RESISTORS
R2510,2514,2539,2543 RS1/16S4701F
R2513 RAB4C472J
R2523 RS1/16S4702F
R2524,2531 RS1/10S224J
R2530,2532 RS1/16S1501F
R2533 RS3LMF151J
R2536 RS1/16S1002F
R2544 RS1/16S4701F
R2550 RS1/16S5601F
R2554 RS1/16S6801F
VR2501 CCP1390
Other Resistors RS1/16S###J
CAPACITORS
C2501,2502,2514 CEHAT101M25
C2503,2515 (330 pF/ 100 V) ACG1105
C2504 CKSRYB102K50
C2505,2506,2512 CKSRYB104K16
C2507 CEHAT221M6R3
Mark No. Description Part No.
C2508 CEHAT221M25
C2509,2510,2518 CKSRYB103K50
C2511,2516 CKSRYB105K6R3
C2513 CKSYB105K25
C2517 CKSRYF104Z50
C2519-2521,2525 CKSRYB104K16
[50Y SCAN BLOCK]
SEMICONDUCTORS
IC2601-2603,2607 TLP116
IC2604-2606 PS9117P
IC2610,2611 TC74AC540FT
MISCELLANEOUS
L2601,2611 BTH1134
CN2601 15P CONNECTOR AKM1200
RESISTORS
R2624 RAB4C220J
R2631 RS1/10S0R0J
Other Resistors RS1/16S###J
CAPACITORS
C2601,2623 CEHAT101M10
C2602,2603,2611-2617 CKSRYB104K16
C2621,2622 ACH1450
C2631 CKSRYB104K16
50Y SUB DRIVE ASSY
SEMICONDUCTORS
Q2701 FKP280AS
Q2711 FKP300AS
Q2721,2723,2725,2726 H5N2512LS
Q2731 QSZ2
D2701 CRH01
MISCELLANEOUS
F2701-2706 ATX1062
K2701 TEST PIN AKX1061
KN2701,2702,2711-2713 ANK1841
GROUND PLATE
CN2701 14P CONNECTOR 14R-FJ
2702 SCREW PMB30P080FNI
RESISTORS
R2702,2712 RS1/10S2R2J
R2722,2724,2726,2727 RS1/10S100J
R2732 RS1/10S0R0J
Other Resistors RS1/16S###J
CAPACITORS
C2701 ACE1178
C2702 ACH1423
C2703 ACG1088
C2711,2721 ACG1139
C2731 CKSYB105K25
[DRIVE HEATSINK M]
MISCELLANEOUS
3001,3001 DRIVE HEATSINK M ANH1656
Mark No. Description Part No.
