Pioneer PDP-507CMX Service Manual

PDP-507CMX
34
1234
1234
C
D
F
A
B
E
RESISTORS
R3611 RAB4C101J
Other Resistors RS1/16SS###J
CAPACITORS
C3609 CKSSYB104K10
C3611 CKSQYB105K16
C3612 ACH1394
C3613 CKSSYB103K16
SENSOR ASSY
SEMICONDUCTORS
IC3651 MM1522XU
IC3652 BR24L02FJ-W
Q3651 HN1B04FU
MISCELLANEOUS
CN3651 CONNECTOR 5P AKM1276
CN3601 PLUG (14P) KM200NA14
RESISTORS
All Resistors RS1/16SS###J
CAPACITORS
C3651,3653 CKSRYB105K6R3
C3652,3654 CKSSYB103K16
C3656,3657 CKSSYB104K10
MAIN ASSY
[CPU BLOCK]
SEMICONDUCTORS
IC9501 MICOM M30700FKNGP
>
IC9502 PQ1U501M2ZPH
>
IC9503 NJM2846DL3-33
IC9504 SN74LVC08APW
IC9505 BD4727G
IC9506 MC74VHCT132ADT
IC9507 RTC-4543SA-B-7
IC9508 24LC128(I)SN
IC9509 TC74VHCT08AFTS1
Q9503 2SA1576A
D9501,9502,9504,9506 1SS301
D9507 RB751S-40
D9508 MZ2J73200L
D9514 RD3R3S(B1)
MISCELLANEOUS
F9501-9503 DTL1034
>
X9501 CRYSTAL RESONATOR ASS1201
CN9501 CONNECTOR 4P AKM1275
CN9503 SOCKET AKP1286
>
BT9501 LITHIUM BATTERY AEX1030
RESISTORS
R9563,9585,9637,9638 RS1/10SR3602F
R9630,9687 RS1/8SQ470J
R9636 RS1/10SR2202F
R9640-9642,9644 RS1/10SR3602F
R9665 RS1/10SR1501F
R9685 RS1/8SQ220J
R9686 RS1/8SQ0R0J
Mark No. Description Part No.
R9688 RS1/10SR2002F
R9692,9693 RAB4CQ103J
Other Resistors RS1/10SR###J
CAPACITORS
C9501,9503,9504,9511 CKSRYB104K25
C9502 CEHVKW470M16
C9505 CKSRYB334K10
C9508 ACG1134
C9509 CKSRYB103K50
C9510,9525,9547 CCSRCH102J50
C9512 CKSQYB105K16
C9514 CKSRYB104K50
C9517 ACH1431
C9518,9522,9528-9530 CKSRYB104K25
C9520,9521 CCSRCH470J50
C9523 CCSRCH391J50
C9524 CKSRYB223K50
C9531,9532 CCSRCH100D50
C9533-9536,9541-9546 CKSRYB104K25
C9537 CCSRCH561J50
C9538 CEHVKW470M6R3
C9540 CCSRCH181J50
[INTERFACE BLOCK]
SEMICONDUCTORS
IC5001 SN74LV14APW
IC5002 SN74LVC14APW
IC5003 BR24C21FJ
IC5004 BA7657F
IC5005 TC74LCX157FTS1
>
IC5006 NJM2846DL3-05
IC5007 EL5362IUZ-T7
IC5008 SN74LVC2G126DCTR
>
IC5009 BA05FP
Q5001-5003,5016,5017 2SC4081
Q5018 DTC144EUA
D5001-5007,5018,5019 UDZS5R6(B)
D5010,5017,5020,5024 1SS301
D5011-5013,5021-5023 1SS302
MISCELLANEOUS
L5001,5002,5004,5005 BTH1102
L5003 BTH1104
F5001,5002,5025 DTL1041
F5003-5007,5010-5012 OTL1046
F5014-5018,5031-5035 OTL1046
CN5001 20P CONNECTOR AKM1343
CN5002,5003 15P D-SUB SOCKET AKP1214
RESISTORS
R5004-5006 RS1/10SR75R0F
R5058,5059,5062,5063 RS1/10SR1501F
R5061,5065,5071 RS1/10SR7500F
R5067,5068 RS1/10SR1501F
R5072,5073,5077,5078 RS1/8SQ111J
R5074-5076 RS1/10SR68R0F
R5082,5083 RS1/8SQ0R0J
Other Resistors RS1/10SR###J
CAPACITORS
C5001,5002,5041,5051 CKSQYB225K16
Mark No. Description Part No.
