Pioneer PDP-507CMX Service Manual

PDP-507CMX
41
5678
56
7
8
C
D
F
A
B
E
R323,334,336 RS1/10SR1001F
R324 RS1/10SR2201F
R325 RS1/16S1200F
R335 RS1/10SR1302F
R339 RS1/16S183J
R352-354,379-383 RS1/10S0R0J
R373 RS1/10S4R7J
R374,405 RS1/10S100J
R375,377,378 RS1/10S103J
R384,385 RS1LMFR68J
R386 ACN1265
R388-390 RS1/10S511J
R391 RS1/16SS104J
R397 ACN1266
R398 RS1/10S0R0J
R402 RS1/16S0R0J
Other Resistors RS1/10SR###J
CAPACITORS
C301,313,320 ACH1459
C302,303,314,321 CKSRYB104K25
C304 CCSRCH101J50
C305,308 CKSRYB103K50
C306 ACH1458
C307,311,312,349 CCG1195
C309 CKSRYB272K50
C310,315 CKSRYB474K10
C316,317,351,352 CCSRCH102J50
C318 CKSRYB681K50
C322 CKSRYB334K10
C323 ACH1462
C324 CKSRYB222K50
C325,345 CKSRYB105K10
C326 CKSYB105K25
C327,328 ACH1461
C329 CKSRYB104K50
C330 CKSRYB102K50
C332,336-338,350 CKSRYB104K25
C334,335 CCH1687
C339,340,343,344 CKSQYB105K16
C341 CKSQYB474K25
C342 BCG1060
C346 CCSRCH151J50
C353 CKSRYB104K25
POWER SUPPLY UNIT
POWER SUPPLY Unit has no service part.
Mark No. Description Part No.
