(1) PACKING PARTS LIST
(2) CONTRAST TABLE
PDP-507CMX/KUC, PDP-50MXE20/LDFK5, TYVXK5 and PDP-50MXE20-S/LDF5 are constructed the same
except for the following:
Mark
No. Description Part No.
> 1Power Cord (2 m) See Contrast table (2)
2 Remote Control Unit AXD1528
NSP 3 Dry Cell Battery (R06, AA) See Contrast table (2)
4 Filter (L10 to L12) CTX1054
5Ferrite Core (L13) See Contrast table (2)
6 Binder See Contrast table (2)
7 Binder Assy AEC1908
8 Cleaning Cloth AED1285
9 Operating Instructions See Contrast table (2)
(English/French/Japanese)
10 Operating Instructions See Contrast table (2)
(English/French/German/Italian/
Dutch/Spanish/Chinese)
11
Operating Instructions (CD-ROM)
See Contrast table (2)
12 Image Caution Sheet ARM1220
13 Caution Sheet ARM1245
NSP 14 Warranty Card See Contrast table (2)
15 Supplement Sheet See Contrast table (2)
16 Power Cord Case See Contrast table (2)
17 Polyethlene Bag AHG1310
18 Polyethlene Bag S AHG1338
19 Pad BL (507) See Contrast table (2)
20 Pad BR (507) See Contrast table (2)
21 Pad TL (507) See Contrast table (2)
22 Pad TR (507) See Contrast table (2)
23 Reinforce Pad (50) See Contrast table (2)
24 Under Carton (507) See Contrast table (2)
25 Upper Carton See Contrast table (2)
26 Mirror Mat See Contrast table (2)
27 Mirror Mat S AHG1399
28 Caution Card See Contrast table (2)
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-507CMX
/KUC
PDP-50MXE20
/LDFK5
PDP-50MXE20
/TYVXK5
PDP-50MXE20-S
/LDF5
> 1Power Cord (2 m) ADG1215 Not used Not used Not used
NSP 3 Dry Cell Battery (R06, AA) VEM1031 AEX1025 VEM1031 AEX1025
5Ferrite Core (L13) Not used ATX1039 ATX1039 ATX1039
6 Binder Not used AEC-093 AEC-093 AEC-093
9 Operating Instructions
(English/French/Japanese)
ARD1075 Not used Not used Not used
10 Operating Instructions
(English/French/German/Italian/Dutch/
Spanish/Chinese)
Not used ARE1466 ARE1466 ARE1466
11 Operating Instructions (CD-ROM) Not used ARU1002 ARU1002 ARU1002
NSP 14 Warranty Card ARY1146 ARY1149 ARY1149 ARY1149
15 Supplement Sheet ARM1328 ARM1328 Not used ARM1328
16 Power Cord Case Not used AHC1095 AHC1094 AHC1095
19 Pad BL (507) AHA2612 AHA2612 AHA2621 AHA2612
20 Pad BR (507) AHA2613 AHA2613 AHA2622 AHA2613
21 Pad TL (507) AHA2614 AHA2614 AHA2623 AHA2614
22 Pad TR (507) AHA2615 AHA2615 AHA2624 AHA2615
23 Reinforce Pad (50) AHC1088 AHC1088 AHC1093 AHC1088
24 Under Carton (507) AHD3473 AHD3473 AHD3498 AHD3473
25 Upper Carton (507CMX) AHD3505 Not used Not used Not used
25 Upper Carton (MXE) Not used AHD3507 AHD3551 Not used
25 Upper Carton (MXE-S) Not used Not used Not used AHD3508
26 Mirror Mat AHG1284 AHG1284 AHG1327 AHG1284
28 Caution Card ARM1329 ARM1329 ARM1330 ARM1329
