Pioneer SC-LX81 Operating Instructions

Additional information
15
130
En
Specifications
Amplifier Section
Multi channel simultaneous power output (1 kHz, 1 %, 8 Ω)
7ch total . . . . . . . . . . . . . . . . . 700 W (LX81), 630 W(LX71)
Continuous Power Output (Multichannel)
(DIN 1 kHz, THD 1 %, 6 Ω)
Front. . . . . . . 190 W + 190 W (LX81), 180 W + 180 W (LX71)
Center . . . . . . . . . . . . . . . . . . . . . 190 W (LX81), 180 W (LX71)
Surround . . . . . . . . . . . . . . . . . . . . . . . .190 W + 190 W (LX81)
180 W + 180 W (LX71)
Surround back . . . . . . . . . . . . . . . . . . .190 W + 190 W (LX81)
180 W + 180 W (LX71)
Total harmonic distortion. . . . . . . . . . . . . . . . . . . . . . . . 0.05 %
(20 Hz to 20 kHz, 130 W, 8 Ω)
Rated Power Output – Stereo (20 Hz to 20 kHz, 0.09 %, 8 Ω)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 W+140 W
• The above specifications are applicable when the
power supply is 230 V.
Audio Section
Input (Sensitivity/Impedance)
PHONO MM . . . . . . . . . . . . . . . . . . . . . . . . . . 4.2 mV/47 kΩ
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335 mV/47 kΩ
Frequency Response (LINE) . . . . . . 5 Hz to 100 000 Hz dB
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335 mV/2.2 kΩ
Signal-to-Noise Ratio (IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103 dB
Signal-to-Noise Ratio
[DIN (continuous rated power output/50 mW)]
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 dB/65 dB
Composite Video / S-Video Section
Input (Sensitivity/Impedance) . . . . . . . . . . . . . . . .1 Vp-p/75 Ω
Output (Level/Impedance) . . . . . . . . . . . . . . . . . . . 1 Vp-p/75 Ω
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 dB
Frequency Response . . . . . . . . . . . . . . . . . . . . 5 Hz to 10 MHz
Component Video Section
Input (Sensitivity/Impedance) . . . . . . . . . . . . . . . .1 Vp-p/75 Ω
Output (Level/Impedance) . . . . . . . . . . . . . . . . . . . 1 Vp-p/75 Ω
Signal-to-Noise Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . .65 dB
Frequency Response . . . . . . . . . . . . . . . . . . . 5 Hz to 100 MHz
HDMI Section
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-pin
Output . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-pin (5 V, 100 mA)
Network Section
LAN terminal . . . . . . . . . . . . . . . . . . .10 BASE-T/100 BASE-TX
USB Section
USB terminal . . . . . . . . . . . . . . . . . . . . . . . USB2.0 Full Speed
FM Tuner Section
Frequency Range . . . . . . . . . . . . . . . . . 87.5 MHz to 108 MHz
Antenna Input . . . . . . . . . . . . . . . . . . . . . . . .75 Ω unbalanced
AM Tuner Section
Frequency Range . . . . . . . .531 kHz to 1602 kHz (9 kHz step)
530 kHz to 1700 kHz (10 kHz step)
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Loop antenna
Miscellaneous
Power Requirements
. . . . . . . . . . . . . . . . . . . AC 220 V to 230 V/240 V, 50 Hz/60 Hz
Power Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330 W
In standby . . . . . . . . . . . . . . . . 0.5 W (HDMI Control OFF)
0.7 W (HDMI Control ON)
Dimensions . . . . 420 (W) mm x 200 (H) mm x 459.5 (D) mm
Weight (without package) . . . . . . . . . . . . . . . . . . . . . . 18.5 kg
Furnished Parts
Setup microphone (for Auto MCACC Setup) . . . . . . . . . . . . 1
AA/IEC R6P dry cell batteries. . . . . . . . . . . . . . . . . . . . . . . . . 2
Remote control unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Flat-bladed converter plug . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
These operating instructions
Note
•Specifications and the design are subject to possible
modifications without notice, due to impr ovements.
