Pioneer XR-P770F Operating Instructions

CONTENTS
CAUTIONS REGARDING HANDLING. ...........:-:sccssseressssseserereressene 3
CONFIRM SUPPLIED ACCESSORIES .......ssssccssssssssesererenserssenvers 4
LOADING BATTERIES INTO REMOTE CONTROL UNIT ............ 4
REMOTE CONTROL OPERATIONS ........:.ccccssessoescsesseaes we 4
CONNECTIONS. .........cscccsscscsorsesnesnees 5
FRONT PANEL FACILITIES.... 7
SETTING THE CLOCK............. . 10
TURNING ON THE POWER .........cccsssssssssssssessstscssessssorssssencseesees 11
Turning power ON without using the POWER switch .......... 11
TUNING INTO STATIONS ........cscscsscsesorersonsesscoencstscssseessasssscenes 11
Beat cut function ............. coax A
MEMORIZING STATIONS ........csssssscsesescssessacscessssrerseeasoeserenacene 12
Manual presetting............ vee 12
Station call......... ‘ wee 12
RDS (Radio Data System) BROADCAST RECEPTION .............. 13
Function of DISPLAY/RDS button ............csccccocscserssssssseaserease 14
Searching for a desired program by program type
(Program Type Search) ........ssssccssscsccescseressssccereseeseeeensserersns 14
RDS data display ...........ssssscsssserscsscesssesssorsrsstassrseeneeenes 15
CAUTIONS REGARDING COMPACT DISC HANDLING a 16
HOW TO HANDLE CASSETTE TAPES. ...........sescessssssesceecsccecsoes 16
READ THIS BEFORE OPERATING THE CD PLAYER... wee 17
LISTENING TO COMPACT DISCS. ..........cesssssssessssessessorsceessesees 17
Before operating the player ..........ssesssssesssersenee (17
Listening to tracks in order from the first track ...........cccseee 18
Select the disc play MOdE ..........scscssscsesescscesseneseseesseatenesereees 18
CONVENIENT CD FUNCTIONS 19
To play back desired tracks ... . 19
Best selection Memory ........sssesscssssecsssseesseseserensesssserssensasese 19
Programmed play ........ a. 20
To repeat playback (Repeat play) ..........sccssesesssesesecseneessees 21
Random play ........sssssscssessenesereees we 21
Fast track search (Hi-Lite SCAN) .......ssssesccessneressanestonsesesesceeere 22
Previous CISC SCAN ........:-sssecccsccscsessnseesserevsestereeees wee 22
Changing the display .......csssssssesssescscsensenssssesesnensesssssesccusecese 22
Disc title memory ..... wee 23
PLAYING TAPES ....... wee 24
Basic operation ........ we 24
Music search .......... weer 24
RECORDING. ............. . 25
Recording on tape. . 25
COpying a tape 20.0... cessesseccsesessenssessesessessescesensnsesencess 25
A.S.E.S. (Auto Synchro Editing System) .............e0 . 26
SOUND FIELD CONTROL (SFC) OPERATION .. . 27
Selecting a preset sound setting ............... ae 27
Boosting the bass SOUNG ........scssssscsccssseccecseceesseseseceesseeseeentes 27
WAKE-UP TIMER \..ccesesssessssorsssesasccnsciscassesssaseceisconssasanseassssossssees 28
Setting the wake-up timer ...........sccccessssssssscssecessecsscsnesseeseesacere 28
TIMER RECORDING...........004. we. 29
Timer recording Setting ..........ssssscssserescssserserecserensenesteseesesceees 29
SLEEP TIMER ‘sssssiseasssacsiscesscessosscssseosocssessosncantes . 29
CONNECTING ANOTHER UNIT TO THIS UNIT .. . 30
MAINTENANCE .........cccessessccccereccsessensnenensesenes . 30
TROUBLESHOOTING .. we 31
SPECIFICATIONS ........scscssscssesessssssssssersessstscseseesacscacaceeecsencereneees 32
CAUTIONS REGARDING HANDLING
install the unit in a well-ventilated location where it will not be
exposed to high temperatures or humidity.
Do not install the unit in a location which is exposed to direct rays
of the sun, or near hot appliances or radiators. Excessive heat can
adversely affect the cabinet and internal components. Installation
of the unit in a damp or dusty environment may result in a
malfunction or accident. (Also avoid installation near cookers, etc.,
where the unit may be exposed to smoke from oil, steam, or heat.)
Do not install the unit on a tottered stand, nor on an unstable or
inclined surface.
Precautions regarding installation
Placing and using the unit for long periods on heat-generating
sources will affect performance. Avoid placing the unit on heat-
generating sources.
e Install the unit as far away as possible from your TV. Installation
in close proximity to such equipment may cause noise or
degradation of the picture.
eSuch noise may be particularly noticeable when an indoor
antennais used. In such cases, make use of an outdoor antenna,
or turn off the power of the unit.
@ Please place this unit on a level surface.
Ventilation
There is a cooling fan in the rear of this unit. ifthe exhaust vent
is blocked, heat will build up inside, interfering with performance
or causing malfunctions. Therefore, make sure to leave space
between the unit and walls and other equipment to im prove
heat radiation (at least 20 cm at top, 15cm at rear, 15cm at left
side, and 15 cm on right side (looking from the front)).
Condensation
When this unit is brought into a warm room from previously cold
surroundings or when the room temperature rises shvarply,
condensation may form inside and the unit may not be able to
attain its full performance. To prevent this, allow the unitto stand
for about an hour before switching it on or raise the room
temperature gradually.
This productis for general household purposes. Any fail wee due
to use for other than household purposes (such as lon¢ tterm
use for business purposes in a restaurant or use in acar q¢ sship)
and which requires repair will be charged for even durng the
warranty period.
3
