CHART 3204. NOSE GEAR SERVICE TOLERANCES
Refer to
Fig. 32-5a Manufactures Service Service
for Part No. Nomenclature Dimension Dimension Tol. Remark
Fig. No.
1 67146-00 Draglink, upper ID.6235 ID.6230 .002
.6245 .6250
2 87319-03 Bearing, upper drag ** ID.4385 ID.4395 .002
(F632-1) link .4375 .4375
2 65003-45* Bushing ID.375 ID.376 .002
.376 .377
3 67146-00 Drag link upper ID.378 ID.3775 .002
.379 .3795
4 452450 Bearing upper drag ** ID.2495 ID.2495 .002
(FF310-5) link .2505 .2515
5 67144-00 Drag link lower ID.2495 ID.2495 .002
.2505 .2515
6 67144-00 Drag link lower ID.3120 ID.3120 .002
.3130 .3140
7 44386-03 Steering arm ID.4370 ID.4370 .0015
.4385 .4385
8 14976-11 Bushing, steering arm ** ID.312 ID.312 .002 Press Fit
.313 .314
9 67054-03 Trunnion housing drag ID.4415 ID.4415 .0010
link attachment .4425 .4425
10 67026-07 Bearing trunnion housing ID.313 ID.3120 .0025 ##
draglink attachment .314 .3145
11 67054-03 Trunnion assembly main ID.6285 ID.6285 .001
attachment fitting .6295 .6295
12 67026-11 Bearing trunnion ** ID.4390 ID.4390 .002 ##
(FF608-3) assembly attachment .4375 .4410
*Used with 452 474 bearing ## lnstall using Loctite 601.
Rotate while inserting.
**Line ream to this dimension after
installation of new part.
32-20-05
Page 32-28
Revised: August 17, 1982
2E11
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
