CHART 3204. NOSE GEAR SERVICE TOLERANCES (cont)
Refer to
Fig. 32-5a Manufactures Service Service
for Part No. Nomenclature Dimension Dimension Tol. Remarks
Fig. No.
13 67054-03 Trunnion assembly ID.302 ID.302 .0015
assist spring fitting .303 .3035
14 95061-144 Bearing, assist spring ID.249 ID.249 .010 ##
fitting .250 .259
15 67148-00 Tube assembly torque ID.4370 ID.4370 .0015
link fitting .4385 .4385
16 67026-07 Bearing, tube assembly ** ID.313 ID.3155 .0025 Press Fit
torque link fitting .314 .3130 #
17 67148-00 Shimmy damper fitting ID.3745 ID.3745 .0017
.3760 .3762
18 21831-04 Shimmy damper fitting ** ID.249 ID.249 .003
bearing .251 .252
19 20735-05 Torque link ID.312 ID.3155 .0025
.314 .3130
20 20735-05 Torque link ID.377 ID.377 .002
.3785 .3790
21 452 366 Bearing, torque link ** ID.2495 ID.2495 .002
(#F-310-5) .2505 .2515
22 67050-02 Fork assembly-torque ID.4370 ID.4370 .0015
link fitting .4385 .4385
23 67026-07 Bearing, fork assembly ** ID.312 ID.312 .003 Press Fit
torque link fitting .313 .315
24 67146-00 Draglink, upper ID.372
.373
25 63900-120 Bushing, upper draglink ID.2495 ID.2495 .010
.2500 .2595
##Install using Loctite 601. ** Line ream to this dimension # Coat with zinc chromatic and install
Rotate while inserting. after installation of new part. while still wet.
32-20-05
Page 32-29
Revised: August 17, 1982
2E12
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
