9  Lower Limit Setpoint 1
AI1 lower limit setpoint.
-999…+9999 digit
3
(degrees if temperature), Default: 0.
10  Upper Limit Setpoint 1
AI1 upper limit setpoint.
-999…+9999 digit
3
(degrees if temperature), Default: 1750.
11  Sensor 2
Analogue input 2 con guration / sensor selection AI2.
**Select dip-switches as indicated on 5.1
   Disabled (Default)
 Tc-K -260…1360 °C
 Tc-S -40…1760 °C
 Tc-R -40…1760 °C
 Tc-J -200…1200 °C
 PT100 -200…600 °C
 PT100 -200…140 °C
 NI100 -60…180 °C
 NTC10K -40…125 °C
 PTC1K -50…150 °C
 PT500 -100…600 °C
 PT1000 -100…600 °C
 0…10 Volt
 0…20 mA
 4…20 mA
 0…40 mVolt
 Potenc. max 6 Kohm (full scale)
 Potenc. max 150 Kohm (full scale)
 Current measured by amperometric transformer
12   Decimal Point 2
Select decimal type visualized for analogue input 2.
 Default
 1 Decimal
 2 Decimals
 3 Decimals
3
The display of the decimal point depends on the setting of parameter . and    or
 and  
