50 ATR401 - User manual
   Processes di erence
 Processes di erence as absolute value
 AI1+AI2 Input addition
87     Visualization Type
Set visualization type on display
 Display 1 process + Display 2 as     (Default)
 Display 1 process + Display 2 as     hidden after 3 sec.
 Display 1 as     + Display 2 process
 Display 1 as     + Display 2 process hidden after 3 sec.
88  Retransmission
Retransmission for output 0…10 V or 0/4…20 mA. Parameters 90 and 91
de nes upper/lower limit of scale
   Disabled (Default)
  Command Setpoint
 Process 1
 Process 2
 Processes Mean
   Processes Di erence
 Processes Di erence as absolute value
 AI1+AI2 Input addition
89   Retransmission Type
Select retransmission type
 0…10 Volt (Default)
 0…20 mA
 4…20 mA
90    Lower Limit Retransmission
Lower limit analogue output range
-999…9999 digit
14
(degrees if temperature), Default: 0.
91  Upper Limit Retransmission
Upper limit analogue output range
-999…9999 digit
14
(degrees if temperature), Default: 1000.
14
The display of the decimal point depends on the setting of parameter . and    or
 and  
