ATR 621 - User manual 33
ATR621 - 12ABC
Command Alarm 1 Alarm 2

Q1 Q2 SSR

Q1 (open) - Q2 (close) SSR -
 
SRR Q1 Q2
ATR621 - 14ABC
Command Alarm 1 Alarm 2 Alarm 3

Q1 Q2 Q3 Q4

Q2 (open) - Q3 (close) Q1 Q4 -
ATR621 - 13ABC-T
Command Alarm 1 Alarm 2 Alarm 3

Q1 Q2 Q3 SSR

Q2 (open) - Q3 (close) Q1 SRR -
 
SRR Q1 Q2 Q3

4...20mA Q1 Q2 Q3

0...20mA Q1 Q2 Q3

0...10V Q1 Q2 Q3
2  Sensor
Analogue input 1 con guration.
 Tc-K: -260..1360°C >Default
 Tc-S: -40…1760°C
 Tc-R: -40…1760°C
 Tc-J: -200…980°C
 Tc-E: -260…740°C
 Tc-N: -260…1280°C
 PT100: -200…600°C
 0…10Volt
 0…20mA
 4…20mA
 Setpoint (setpoint value is visualized as process)
