34 ATR 621 - User manual
3  Decimal Point
Selects type of visualized decimal point.
 > Default



4    Lower Linear Input
AI1 lower limit range, only for linear.
-999…+9999 [digit
4
]. Default: 0.
5  Upper Linear Input
AI1 upper limit range, only for linear.
-999…+9999 [digit
4
]. Default: 1000.
6  O set Calibration
O set calibration. Number added to visualized process (normally it
corrects ambient temperature value).
-999…+1000 [digit
4
]. Default: 0.0.
7   Gain Calibration
Gain calibration. Number multiplied with process value to calibrate
working point.
-99.9%…+100.0%. Default: 0.0.
8    Lower Limit Setpoint
Setpoint lower limit.
-999…+9999 [digit
4
] (degrees.tenths for temperature sensors). Default: 0.
9  Upper Limit Setpoint
Setpoint upper limit.
-999…+9999 [digit
4
] (degrees.tenths for temperature sensors). Default:
1750.
10  Degree
Select degree type
 Centigrade. > Default.
 Fahrenheit.
