36 ATR 621 - User manual
20  Proportional Band
Process inertia in units (Ex: if temperature in °C)
0 ON/OFF if also  equal to 0. > Default.
19999 [digit
4
] (degrees.tenths for temperature sensors ).
21  Integral Time
Integral time. Process inertia in seconds.
0.0999.9 seconds. 0 disabled integral. > Default: 0.0.
22  Derivative Time
Derivative time. Normally ¼ of integral time.
0.0999.9 seconds. 0 disabled integral. > Default: 0.0.
23  Cycle Time
Cycle time (for P.I.D. on contactor 10/15”, for P.I.D. on SSR 1). For time-
proportioned valves see Par. 43.
1…300 seconds. > Default: 10.
24  Lower Limit Output Percentage
Selects min. value for command output percentage.
0…100% > Default: 0%.
25  Upper Limit Output Percentage
Selects max. value for command output percentage.
0…100% > Default: 100%.
26  Command State Error
Contact status for command output in case of error.
 (Open Contact) > Default
  (Contact closed).
27  Digital Input
Digital input functioning.
 (Disabled). > Default.
 Temporary regulation lock input (holding cycle,

on
display and command output switching o ).
 (Emergency) Emergency input: device stops. It visualizes

with active buzzer until pressing OK.
