ATR 621 - User manual 37
 Cycle pause with sepoint modi able by keyboard.
  (Run Cycle 1) active RUN input:cycle 1 starts
   (Run Cycle 2) active RUN input:cycle 2 starts
  (Run Cycle 3) active RUN input:cycle 3 starts
  (Run Cycle 4) active RUN input:cycle 4 starts
  (Run Cycle 5) active RUN input:cycle 5 starts
  (Run Last Cycle) active RUN input:starts the last cycle done
  (Run Thermoregulator) active RUN input: thermoregulator
function starts
     (Run Manual) active RUN input: manual mode starts
 Input for manual autotuning function
28  Digital Input Contact Type:
 (Open Contact)
  (Contact closed) > Default
29     Visualization Display 2
Set visualization on display 2 during a cycle.
(End Step Setpoint) Operating step end temperature
    (Real Setpoint) Updated according to the selected gradient
 (Cycle Number) Number of operating cycle. > Default.
(Step Number) Number of operating step
    Time elaplsed from cycle start
(Output Percentage)
30  Delaied Start
Enables initial waiting for delayed start of cycle.
   (Disabled) Initial waiting disabled. > Default.
 (Enabled) Initial waiting selectable by the user.
31  Starting Setpoint
Enables cycle starting setpoint to guarantee the programmed gradient
for the  rst step.
   (Disabled) Cycle starting setpoint disabled. > Default.
 (Enabled) Cycle starting setpoint selectable by the user.
(Enabled Ambient Temperature) Fixed cycle starting setpoint
(25°C for temperature sensors and 0 for linear sensors).
