42 ATR 621 - User manual
 (Start Alarm). Active in RUN.
(End Alarm). Active at cycle end.
Auxiliary Output Related to the Step). ON/OFF at each step.
(Auxiliary Output Rising Maintenance). Auxiliary output active
for rising and holding steps
 (Auxiliary Output Falling). Auxiliary output active for falling steps.
 (Cooling). Actuator output for cooling during double loop
functioning.
60  Alarm 3 State Output
Selects contact type for alarm 3 output.
 (Normally Open). > Default.
 (Normally Closed).
61   Alarm 3 Threshold
Selects setpoint value for alarm 3.
-999…+9999 [digit
4
] (degrees for temperature sensors). > Default: 0.
62  Alarm 3 Hysteresis
Selects hysteresis for alarm 3.
-999…+999 [digit
4
] (degrees.tenths for temperature sensors). > Default: 1.0.
63  Alarm 3 State Error
Contact satus for alarm 3 output in case of error.
 (Open Contact) > Default
  (Contact closed)
64  Alarm 3 Led
De nes led A3 status corresponding to relevant contact.
 (Open Contact)
  (Contact closed) > Default
65  Alarm 3 Action Type
De nes alarm 3 action type on operating cycle.
 (No Action). Changes only output related to the alarm. > Default.
 (End Cycle Signal). Cycle ends (STOP) with acoustic and visual
signalling. Changes output related to the alarm, buzzer sounds
and on display  ashes , until pressing OK.
 (Audible Signal). Only acoustic signalling: buzzer sounds.
