27.8 Manual control of output
21
This functions allows to control/modify manually the command
output to exclude automatical control of process. The output is
activated as percentage 0 - 100% according to the time basis
entered on parameter P-30 (cycle time).
Set the controller to mode and follow the points below:
Press Display Do
1
Red display shows
available options
2
Increase/decrease until
is visualized
3
Green display shows
percentage of outputThe
controller activates the
output.
4
Visualize percentage value
of output 1 (cycling also
value of output 2 if
enabled).
To modify percentage
press funtil red
display shows
(or if two
process are enabled)
and press to
modify value.
To quit the function press
21
Access to this function can be denied on P-01, 3
rd
digit.
