Pixsys ATR620 User Manual

55
22 Technical data
22.1 Main features
Visualizers
4 displays 0,56 inches
4 displays 0,28 inches
Operating temperature 0-45°C, humidity 35..95uR%
Sealing
IP54 Frontal, IP30 box, IP20 terminals
block
Material Noryl 94V1 self-extinguishing
Weight 400g
22.2 Hardware data
Analog input
1: AN1, AN2
Software configurable
Input An. 1
Thermocouple K, S, T, R, J, E
RTD type PT100, Ni100
Input An. 2
Thermocouple K, S, T, R, J, E
Input 0-1V, 0-10V,0-20mA, 4-
20mA
Accuracy
(25°C)
0.2 % ± 1 digit
for input TC,
RTD , V, mA
Relay outputs
2/3 relays: OUT, A1, (A2)
Configurable for command or
alarm
Contacts 8A-
250V~
SSR output
1 output: A2
Configurable for command or
alarm
Output 12Vdc
30mA
Serial input
1: RS485 , Modbus protocol
Digital input
1: IN1, IN2
Configurable as Input START/STOP, signal
, HOLD input
