Input Menu
EP Series Ultra HD LCD Displays User Guide 25
Source 3
Select the third source
Options: DP1, DP2, HDMI1, HDMI2, HDMI3, HDMI4, VGA, OPS
Note: This function is only available when Multi-Source Views is set to Quad View. If
HDMI4 was selected as another source, OPS cannot be selected. If OPS was selected as
another source, HDMI4 cannot be selected.
Source 4
Select the fourth source
Options: DP1, DP2, HDMI1, HDMI2, HDMI3, HDMI4, VGA, OPS
Note: This function is only available when Multi-Source Views is set to Quad View. If
HDMI4 was selected as another source, OPS cannot be selected. If OPS was selected as
another source, HDMI4 cannot be selected.
PIP Size
Select the size of the PiP (Picture-in-Picture)
Options: Small, Mid, Large
Note: This function is only available when Multi-Source Views is set to PiP.
PIP Position
Set the position of the PiP (Picture-in-Picture)
Options: TopR ( Top Right), TopL (Top Left), BotR (Bottom Right), BotL (Bottom Left)
Note: This function is only available when Multi-Source Views is set to PiP.
Input Swap
Swap the Main Input source with Source 2
Note: This function is only available when Multi-Source Views is set to PiP or Dual View.
Multi-Source Presets
Save or Recall Multi-Source Preset1, Preset2, Preset3 or Preset4
Note: See page 26 for more information.
