PLANET ECLIPSE GEO 4 - Page 26

FIG-1
26
AVAILABLE PRESETS
The default list of presets are listed below:
> SEMI NC: Uncapped semi-automatic.
> SEMI 10: Semi-automatic capped at 10 bps.
> SEMI 15: Semi-automatic capped at 15 bps.
> NXL 2016: Ramping capped at 10.2 bps compliant with 2016 NXL Rules.
> PSP 2015: Ramping capped at 10.2 bps compliant with 2015 PSP Rules.
> RETRO: NXL style ramping capped at 5.5 bps.
> USER 1: User dened preset
> USER 2: User dened preset
Note: If the factory settings are restored using the RESET > FACTORY item in the
HARDWARE menu then the user presets will be reset to the factory defaults.
FIG-1 PRESET PARAMETERS
Select the required preset from the list of available presets (above).
1, 2
1 Some presets may only be available in certain countries and on some models of the GEO 4.
2 All presets are correct at the time of printing.
ELECTRONICS
USER INTERFACE PARAMETERS
