27
ELECTRONICS
USER INTERFACE PARAMETERS
FIG-1 - FIRE MODE PARAMETER
Sets the ring mode of the marker.
> SEMI: 1 shot per trigger pull.
> RAMP: Ramping, multiple shots per trigger pull
under certain conditions. See page 28.
FIG-2 - ROF CAP PARAMETER
The maximum rate of re the marker can achieve.
> ON: ROF limited to the BS ON ROF value.
> OFF: ROF limited by loader speed.
FIG-3 - BS ON ROF PARAMETER
Sets the maximum rate of re the marker can
achieve with the breech sensor (BS) enabled.
This parameter is only available if the ROF CAP is
set to ON.
> Range: 4.0 - 20.0 bps (balls per second)
in 0.1 increments.
1
1 Always calibrate your ROF CAP parameters to the local eld
meter for consistency.
FIG-4 - BS OFF ROF PARAMETER
Sets the maximum rate of re the marker can
achieve with the breech sensor (BS) disabled.
This should be set to the slowest feed rate of the
loader in order to avoid chopping paintballs.
> Range: 4.0 - 15.0 bps (balls per second)
in 0.1 increments.
1
1 Always calibrate your ROF CAP parameters to the local eld
ROF meter to avoid penalties.
