PLANET ECLIPSE GEO CS1 - Page 29

FIG-2
FIG-1
FIG-3
FIG-4
29
GEO:CS1
ELECTRONICS
USER INTERFACE PARAMETERS
FIG-1 - HARDWARE MENU
The HARDWARE menu contains low level functionality from the CS1 electronic hardware.
FIG-2 - TRIGGER PARAMETER
This allows the user to select their trigger detection
system preference.
OPTO is the factory default selection.
> OPTO: OPTO-Electronic trigger pull sensor.
> SWITCH: Microswitch trigger pull detection.
> CANCEL: Editing is cancelled and unchanged.
FIG-3 - SOUND PARAMETER
Startup sounds, parameter changing sounds and
alarms can all be switched to silent if required.
> ON: Default sounds On.
> OFF: Default sounds O.
> CANCEL: Editing is cancelled and unchanged.
FIG-4 - TONES PARAMETER
The push button tones can be switched o with
all other sounds still audible, if the SOUNDS
parameter is set to On.
> ON: Default tones On.
> OFF: Default tones O.
> CANCEL: Editing is cancelled and unchanged.
