- 16 -
4-2 System
This section provides System Information, IP Configuration, Password Setting, Alert Trap, Factory Default, Firmware
Update and Reboot functions of Web Smart PoE Switch, the screen in Figure 4-3 appears and table 4-1 describes the
System object of Web Smart PoE Switch.
Figure 4-3 System Web Page Screen
Table 4-1 Descriptions of the System Web Page Screen Objects
Object Description
System Information
Display the MAC address, Hardware Version, and Software Version, Device Description. Ex-
plained in section 4.2.1.
IP Configuration
Allow to change the IP subnet address of Web Smart PoE Switch. Explained in section 4.2.2.
Password Setting
Allow to change the username and password of Web Smart PoE Switch. Explained in section
4.2.3.
Alert Trap
Allow configure the Alert Trap function of Web Smart PoE Switch. Explained in section 4.2.4.
Factory Default
Allow reset the Web Smart PoE Switch to factory default mode. Explained in section 4.2.5.
Firmware Update
llow proceed firmware upgrade process of Web Smart PoE Switch. Explained in section
4.2.6.
Reboot
Allow reboot the Web Smart PoE Switch. Explained in section 4.2.7.
