4.3.2 Port Mirroring
Thi on introduces detail s Figure 4-22
app 4-6 descript
s secti ettings of Port Mirroring function of Web Smart PoE Switch; the screen in
ears and table ions the Port Mirroring objects of Web Smart PoE Switch.
Table 4-6 Descriptions of the Port Mirroring Screen Objects
Figure 4-22 Port Mirroring Web Page Screen
Object Description
Monitored Packets
Provide disable and enable the Port Mirroring function, the available options are Disable, RX,
TX, TX & RX.
Default mode is Disable.
Destination Port
The destination port can be used to see all monitor port traffic. It can connect destination port to
LAN analyzer or Netxray.
Source Port
The source port that want to monitor. All monitor port traffic will be copied to destination port.
Apply button
Press this button for save current configuration of Web Smart PoE Switch.
